Build Feature - Black Project STI



Build Feature🔥

Today’s In-depth featured ride is an amazing Subaru STI @blackprojectsti 🖤‼️🖤‼️


1) how long have you owned the car “About 5.5 years, it’s a 2011 WRX STI hatch, I bought it in 2015 after I sold my 2004 WRB STI. I miss it sometimes but it was time to let it go and move onto something else!” 2) what’s your next mod “I’m in a transition period. The car is fully built and setup for solid power, I’m enjoying it for what it is at the moment. To narrow it down adding Flex Fuel to run e85 is the main goal. Aiming for around 550-600whp that’s the sweet spot for my setup. I have plans for a rotated setup, flares and wider wheels, seats, roll cage etc. I have been putting off frontend aero (splitter, canards, etc) for awhile because I send it year round in North NJ and that’s risky business without bags, but I might just do it anyway soon…I’m not even close to done with the car yet!”

3) what’s your favorite angle “100% it is low to the ground from the back left, it’s her “good side” I think!” 4) horsepower numbers /torque437whp/363wtq on 93 / JR Tuned on a mustang dyno at Prime Motoring in NJ. I am still catted so numbers are a little lower than I want for 93 with the FP Black turbo but the thing rips for an intermediate setup!” 5) if you could have any car what one? “Skyline r34 or any of the older Supra’s, I’m a sucker for those!





MOD LIST


SHORT BLOCK

  • Block - IAG Stage 2.5 EJ25 Closed Deck Short Block

  • Crankshaft - Standard New Subaru Nitride Treated 2017+ STI

  • Pistons - Manley 99.75mm Platinum Forged

  • Wrist Pins - Manley Extreme .250" Thick-Wall

  • Connecting Rods - IAG Spec H-Beam

  • Rod Bolts - ARP 625+

  • Rod / Main Bearings - ACL

  • Case / Main Bolts – Standard FHI Subaru Case Bolts

  • Oil Pump - Subaru 11mm

  • Head Gaskets - Cosworth 1.1mm

Heads

GSC Power-Division

  • S2 Billet Core Intake/Exhaust Cams (272/272) w/ Dual AVCS

  • Stainless Steel Exhaust Valves 32mm

  • Stainless Steel Intake Valves 36mm

  • Single Beehive Valve Spring Set w/ Titanium Retainers

ARP

  • Custom Age 625+ Head Stud Kit


Engine

IAG

  • CNC Top Feed TGV Deletes

  • IAG Competition Series AOS

Other

  • Torque Solutions Air Pump Delete Plate Set

  • Fluidampr Harmonic Balancer Crank Dampener

  • Gates Timing Kit w/ HKS Fine-Tune Timing Belt

  • Iridium One-Step Colder Spark Plugs

Drive Train

ACT

  • Heavy Duty Performance Street Disc Clutch Kit (HDSS)

  • Streetlite Steel Flywheel

Cobb

  • Short Throw Shifter

  • Shifter Bushings

Kartboy

  • Pitch Stop Mount

Perrin

  • Transmission Mount

Aluminati

  • Solid Motor Mounts

  • Solid Transmission Cross Members


Fuel System

Aeromotive

  • Top Feed Fuel Rail System Kit w/ Adjustable FPR

Injector Dynamics

  • 1300x² Top Feed Fuel Injectors

  • Fuel Injector Plug n Play Adapters

Radium Engineering Fuel Pump Hanger

  • Walbro 450LPH Fuel Pump

  • Fuel Pump Inlet Hanger Sock

  • Fuel Hanger Plumbing Kit

  • DIY Wiring Kit


Power

Forced Performance

  • Black HTZ Turbocharger

  • Ceramic Coated 10cm Hot Side

  • Ported Turbine Housing


  • 84mm Turbo Inlet

PTP

  • T25/28 Turbo Blanket

Perrin

  • Cold Air Intake

  • Grimmspeed MAF Block-Off Plate


  • Front Mount Intercooler

  • Black Core / Black Couplers / Red Tubes


Cobb

  • Catted Downpipe

HKS

  • Stainless Steel ELH

  • Ceramic Coated by Intuitive Powder


  • SSQV4 BOV

  • Ceramic Coated by Intuitive Powder

  • Torque Solutions BOV Adapter Flange


Grimmspeed

  • EBCS

  • Ceramic Coated Uppipe

Tial

  • 38mm EWG

Greddy

  • Spectrum (SP) Elite Catback Exhaust

Oil / Cooling

Mishimoto

  • Silicone Radiator Hose Kit

  • Stainless Steel Braided Oil Hoses

  • Heatshield Products Fire Shield Sleeves


Killer B

  • High Flow Water Pump Housing

  • Aluminum Oil Pan

  • Baffle

  • Pickup

Other

  • Aluminati Coolant Expansion Tank

  • Cobb Expansion Cap 1.1 Bar


  • Perrin Oil Sandwich Adapter

  • CSF Racing Aluminum Radiator with Oil Cooler

  • APR Carbon Fiber Radiator Cooling Plate

  • GETaDOMTUNE Cylinder 4 Chamber Cooling System

  • KStech Hood Scoop Block-Off for FMIC

Tune

  • Cobb V3 Access Port

  • Visconti Speed Density Kit w/ IAT

  • Speed Density 93 Tune by JR Tuned [437whp/363wtq]

Suspension

GTWORX/Bilstein Struts

  • Impreza Cup Sport Kit

Racecomp Engineering

  • Yellow Springs

  • Front and Rear Sway Bars

Whiteline

  • Sway Arm Links

Kartboy

  • Front and Rear End Links

  • Positive Traction Kit

  • Subframe Inserts

  • Front and Rear Shifter Bushings

Perrin

  • Rear Differential Lockdown

  • Positive Steering Response System

  • Steering Rack Lockdown

  • Front Control Arm Bushing Kit

Tanabe

  • Front Strut Tower Bar

Moog

  • Outer Tie Rods

Exterior

  • AeroFlow Dynamics v1 Rear Diffuser

  • Varis Style Wing

  • JNA Front Lip

  • C-Speed Side Skirts

  • Grillcraft Front and Lower Grill

  • Sickspeed Triangle Rear Tow Hook

  • Rally Armor Mud-Flaps

  • Hella Horns w/ Subimods Mount

  • Subaru OEM Window Deflectors

  • 20% Window Tint

  • Emblem Overlays

  • Fender STI Logo Badges and Pinstripe

  • STI Badges

  • Front Grill Pinstripe

  • 3M Gloss Black Window Pillar Vinyl Wrap

  • 3M 3D Carbon Fiber Hatch Wrap

  • Front Emblem Gloss Black Vinyl Chrome Delete

  • GOGOCARBON Carbon Fiber Rear Tailgate Trunk Lid Garnish

Head Lights

LightWerkz Quad HID Projector Retrofit

  • Morimoto

  • Mini H1 Bixenon Projectors

  • 35w D2S 5500k Bulbs

  • XBT Controller


  • Hylux

  • HID System 35w Ballasts


  • Profile Prism

  • (RGB) 90mm/80mm Halos

  • (RGB) Demon Eyes


  • SubieLED

  • Switchbacks (1157)


  • Headlight Housings

  • Tinted Corner Light Reflectors

  • Bezels (painted gloss black)

  • Mini Gatling Gun Shrouds (painted red)

  • Low Beam Bezel Shrouds (painted red)


  • Premium Autostyling

  • Gloss Black “Wicked” Eyelids


Fog Lights

  • Custom Projector Retrofit

  • 3000k Ion-Yellow LED Foglight Conversion Kit

Tail Lights

Diode Dynamics

  • Tail-As-Turn Conversion

  • 7440 HP11 Cool White Reverse Lights (x4)

Other

  • iJDMTOY LED Bumper Reflector Lights

  • Xenon White High Power LED License Plate Lights

  • Tail Light Overlays (red)

  • Reverse Light Overlays (smoke)

Interior

JPM Coachworks

  • Alcantera Radio Dash Kit

  • Alcantera Shift Boot Bezel

  • Alcantera Center Arm Rest

JDMFV

  • Carbon Fiber and Gloss Red Door Sill Overlays

  • Steering Wheel Overlay

SMY

  • STI Emblems for WeatherTech Mats

  • Door Striker and Hinge Stopper Covers

Perrin

  • Reverse Lockout

  • SI-Drive Cover Knob

Other

  • Seamless Designs Shift Boot

  • Cusco Carbon Fiber E-Brake Handle

  • Shift Solutions Rage Red Anodized Drift Button

  • Weathertech Floor Mats

  • GT-SPEC D Steering Wheel

  • Genuine Subaru Footwell Illumination Lights

  • 3M Hot Rod Red Vinyl Accent Wrap by Flowcustomz

  • Autostyled Red with Black Delrin Shift Knob

  • Sun Visors Wrapped in Red Recaro Fabric by MD Interiors

Gauges

SMY Cluster Dual Gauge Pod (52mm)

  • AEM UEGO Wideband AFR Gauge

  • Visconti TGV Data Logging Harness


  • AEM Boost Gauge

ATI Center Gauge Pod (60mm)

  • Perrin Oil Pressure

  • Perrin Oil Temperature

  • Perrin Fuel Pressure

  • DIY Custom Perrin Gauge Switch Panel

  • DIY Clock Relocation

SMY Defrost Vent Dual Gauge Pod (52mm)

  • SMY Gauge Pod Accessport Mount

  • AEM X-Series EGT (planned)

P3

  • Multi-Gauge Vent Gauge

Engine Dress Up

Perrin

  • Alternator Belt Cover

  • Boost Solenoid Cover

  • Battery Tie Down

  • Oil Filler Cap

  • Master Cylinder Reservoir Cozy

  • Fender Shrouds

SuperStik

  • Precision Oil Dipstick

Billetworkz

  • Black “B” Series Engine Fluid Caps

Axis Japan

  • Carbon Fiber Fuze Box Cover

Brakes

EBC

  • USR Slotted Rotors

  • Red Stuff Brake Pads

Perrin

  • Master Cylinder Brace

StopTech

  • Stainless Steel Brake Lines

Security

Advanced Keys

  • Smart Keyless Entry System

  • Push Button Start Module

  • Automatic Window Closing Module

Valentine One

  • Radar Detector w/ Mirror Mount

Sound

  • AVIC-8100NEX Pioneer In-Dash Nav/Receiver w/ Apple CarPlay

  • Pioneer ND-BC5 Universal Rearview Camera

  • Subwoofer (10” JL W6) in an Audio Integrations Box

  • JL Slash 600w/1v3 Amplifier

  • 4x Hertz Audio ECX 165.5 6.5" Energy Series 2-Way Coaxial Speakers


Wheels - Summer

  • MB Battle 18x9.5” +23 on 245/40/18

  • Powder Coated Gun Metal


Wheels - Winter

  • OEM Gold BBS 18x8.5” +55

  • Michelin X-Ice Xi3 Tires [245/40/18]
